Dimension drawing β all measurements in mm
| Ref | Dimension | Value |
|---|---|---|
| A | Sub-dimension A | 1030 mm |
| B | Sub-dimension B | 1260 mm |
| C | Sub-dimension C | 2200 mm |
| E | Sub-dimension E | 920 mm |
| F | Sub-dimension F | 2020 mm |
| Length (overall) | 2200 mm | |
| Width / Depth | 1030 mm | |
| Height (overall) | 1260 mm | |
| Wt | Weight | 256.0 kg |
